Tank washing machine are specially produced for the tank washing system of oil tanker and chemical tanker with practical design and compact mechanism.The machine renders thorough washing effects of the tank.It is small in size,light in weight,easy to use and maintain.It can be operated as permanently installed system or as a portable unit.Anticorrosive products are made of stainless steel which is available for choices.
| Type | Nozzle Diameter mm | Working Pressure Mpa |
Flow M3/h |
Effective Range m |
DEynamic Pressure Kpa |
||
| Design DATA | Tolerance | Design DATA | Tolerance | ||||
| AM11B(Q)-60 | 11 | 0.8 | 26 | ±5% | 15 | 0-10% | ≥7 |
| 0.7 | 24 | 13 | |||||
| 0.6 | 21 | 12 | |||||
| AM12B(Q)-60 | 12 | 0.8 | 29 | ±5% | 16 | 0-10% | ≥7 |
| 0.7 | 27 | 14 | |||||
| 0.6 | 24 | 13 | |||||
| AM13B(Q)-60 | 13 | 0.8 | 33 | ±5% | 18 | 0-10% | ≥7 |
| 0.7 | 30 | 16 | |||||
| 0.6 | 27 | 15 | |||||
| AM14B(Q)-60 | 14 | 0.8 | 36 | ±5% | 20 | 0-10% | ≥7 |
