Pneumatic Rotary Drill

Drill Size: 22mm or 32mm
Widely used in large-scale mechanical assembly and bridge construction and other metal materials drillings, reaming and Tapping

Send Inquiry Contact US

Pneumatic Scaling Hammer

Pneumatic Lamp

Content

Heavy Duty Pneumatic Rotary Drill
Widely used in large-scale mechanical assembly and bridge construction and other metal materials drillings, reaming and Tapping
Specifications:
Model	PD-22	PD-32
Code	590351	590352
Max. Drilling Dia.	22mm	32mm
Air Pressure	6Bar
Load Speed	300RPM	225RPM
Air Consumption	1700L/MIN	2000L/MIN
POWER	0.95KW	1.14KW
Air Hose ID	16mm	16MM
Taper of Spindle Hole	No.2	No.3
Axial Feed Length	60mm	70mm
Dimensions	532x140x322mm	600x140x330mm
Net Weight	9kg	13kg
